1. SYSTEM INTRODUCTION
1-3
About the soft cover
The soft cover (supplied with TZTL12F/TZTL15F) pro-
tects the LCD when the display unit is not in use. To re-
move the cover, grasp the cover at the locations circled
in the right figure and pull forward.
Touchscreen operations
The tables which follow outline the touchscreen opera-
tions.
Operation with a finger
Operation with two fingers
Operation with a finger Function
Tap Short tap
• Select a menu item.
• Select an object or position to display the cor-
responding pop-up menu.
Long tap
• Edit display icon (on home screen).
Drag • Pan the charts.
• Scroll the menu.
Operation with two fingers Function
Pinch • Zoom in or out the display range in the 2D/
3D modes or weather display.
• Select radar range on the radar display.
Drag Change 3D viewing point.
Tap Do the function assigned to [Function Ges-
ture], which is in the ([Settings] - [General]
menu. See section 1.16.
To Next Page
