FUTABA T18MZ WC - Sensor

105
＜
Linkage Menu
＞
+(/,&237(5
$,53/$1(*/,'(5
9ROWDJH 
9ROWDJH
ŏ5HWXUQWR/LQNDJH0HQX
ŏ6HQVRU,',WLVXQQHFHVVDU\ZKHQXVLQJHYHU\RQH
VHQVRURIVHYHUDONLQGVPD\VWLOOEHVXIÀFLHQW
ŏ7RXFKWKH>6HQVRU@EXWWRQLQWKH/LQNDJH0HQXWR
FDOOWKHVHWXSVFUHHQVKRZQEHORZ
＜
Assignable slot
＞
*Altitude sensors, GPS sensors and other data sensor units may use multiple slots.
*The sensor which uses two or more slots has restriction in a start slot.
6HQVRU
9DULRXVWHOHPHWU\VHQVRUVVHWWLQJ
The telemetry sensor slot number and which sensor
is used in each slot can be changed in this screen.
Since the sensor in each slot is determined at
initialization and the same slot number is memorized
even for sensors sold separately, sensors can be
used by simply connecting them to S.BUS2. When
customizing the sensors yourself, perform the
settings in this screen.
[What is a slot?]
Servos are classified by CH, but sensors are
classified in units called “slot”. There are slots
from #1 to #31.
Altitude sensors, GPS sensors and other data
sensor units may use multiple slots.
By the sensor which uses two or more slots,
the required number of slots is automatically
assigned by setting up a start slot.
When 2 or more of the same kind of sensor
are used, the sensors themselves must allocate
unused slots and memorize that slot.
*Three slots of altitude sensor are used.
*Eight slots of GPS sensor are used.
Sensor
The required
number of slots
The number which can be used as a start slot Selling area
TEMP (SBS-01T,
SBS-01TE)
1slot 1 〜 31
Global
RPM (SBS-01RM,
SBS-01RO, SBS-
01RB)
1slot 1 〜 31
Voltage (SBS-01V) 2slot
1,2,3,4,5,6,8,9,10,11,12,13,14,16,17,18,19,
20,21,22,24,25,26,27,28,29,30
Altitude (SBS-01/02A) 3slot
1,2,3,4,5,8,9,10,11,12,13,16,17,18,19,20,21,
24,25,26,27,28,29
Current (SBS-01C) 3slot
1,2,3,4,5,8,9,10,11,12,13,16,17,18,19,20,21,
24,25,26,27,28,29
S.BUS2 Servo sensor
(SBS-01S)
6slot
1,2,8,9,10,16,17,18,
24,25,26
GPS(SBS-01G) 8slot 8,16,24
TEMP125-F1713 1slot 1 〜 31
Europe
VARIO-F1712 2slot
1,2,3,4,5,6,8,9,10,11,12,13,14,16,17,18,19,
20,21,22,24,25,26,27,28,29,30
VARIO-F1672 2slot
1,2,3,4,5,6,8,9,10,11,12,13,14,16,17,18,19,
20,21,22,24,25,26,27,28,29,30
CURR-F1678 3slot
1,2,3,4,5,8,9,10,11,12,13,16,17,18,19,20,21,
24,25,26,27,28,29
GPS-F1675 8slot 8,16,24
Kontronik ESC 8slot 8,16,24
ROXXY 5slot 1,2,8,9,10,16,17,18,24,25,26
JetCat V10 14slot
1,2,3,4,5,6,7,8,9,10,11,12,13,14,15,16,17,
18
PowerBox 16slot 8,16
