32
Before Use
6%86:LULQJH[DPSOH
%DWWHU\
%DWWHU\
6%86
([WHQVLRQ
FRUG
6ZLWFK
7HUPLQDOER[
+8%
+8% +8%
+8%
+8%
+8%
+8%
ق$QRWKHUSRZHUVXSSO\ك
+8%
ق$QRWKHUSRZHUVXSSO\ك
6%866HUYR
6%866HUYR
Receiver
●S.BUSServo
Since the channel number is memorized by the
S.BUS itself, any connector can be used. When the
SBD-1/SBD-2 (sold separately) is used, ordinary
servos can be used with the S.BUS system.
*SBD-1 cannot be used by S.BUS2 port.
●Whenseparatepowersupplyused
When a large number of servos are used or
when high current servos are used, the servos
can be driven by a separate power supply by
using a separate Power Supply 3-way Hub.
7HUPLQDOER[
Four connectors can be inserted
Three connectors can be
inserted.
Used when using a separate
power supply battery.
6%86
3RUW
6%
Orange
Green
*When using 8/SB as S.BUS, you have to set CH
MODE of the mode B or mode D.
WARNING
Power supply
Please make sure that you use a battery
that can deliver enough capacity for
the number and kind of servos used.
Alkaline batteries cannot be used.
