FLIGHT INSTRUMENTS
HEADING FAILURE MODES
If the system is unable to determine the aircraft heading, but GPS-based track information is available, the
HSI displays the ground track instead of heading using HSI Track Mode. In this mode, a magenta ‘TRK’
annunciation and track readout appear on the HSI. In addition, a yellow ‘HDG’ annunciation with a red X
appear above the ‘TRK’ annunciation to indicate the HSI is displaying track instead of heading.
If both the heading and track are unavailable, the HSI displays a yellow ‘HDG’ annunciation with a red X over
the heading readout box. The system also removes directional numbers and letters from the HSI.
Figure 2-53 Heading Failure Displays on the HSI
HSI Track Mode (Heading Unavailable, Track Available)
Heading and Track Unavailable
NOTE: When heading information is unavailable, the system removes the bearing pointers from the HSI, and
removes wind data from the PFD and navigation maps.
UNUSUAL ATTITUDES
When the aircraft enters an unusual pitch attitude, red extreme pitch warning chevrons pointing toward the
horizon are displayed on the Attitude Indicator, starting at 50Ëš above and 30Ëš below the horizon line.
Figure 2-54 Pitch Attitude Warnings
Nose High
Nose Low
