AUTOMATIC FLIGHT CONTROL SYSTEM
COMMAND BARS
Upon activation of the flight director, Command Bars are displayed in magenta on the PFDs as a single-cue.
The Command Bars do not override the (yellow) Aircraft Symbol. The single-cue Command Bars (Figure 7-5)
move together vertically to indicate pitch commands and bank left or right to indicate roll commands.
Figure 7-5 Single-cue Command Bars
Aircraft Symbol
Command Bars
If the attitude information being sent to the flight director becomes invalid or unavailable, the Command Bars
are removed from the display. The flight director Command Bars also disappear if the pitch exceeds +30˚/-20˚
or bank exceeds 65˚.
