Garmin G1000 Pilot’s Guide for the Socata TBM 850/900
161
AUDIO PANEL AND CNS
PASSENGER ADDRESS (PA) SYSTEM
A passenger address system is provided by pressing the PA Key to deliver messages to the passengers. The
message is heard by the other pilot on the headset only if the other pilot’s PA Key is enabled. PA messages are
one way from the flight deck to the passengers.
A Push-to-talk (PTT) must be pressed to deliver PA announcements to the passengers over their
headphones.
When PA is selected on the Audio Panel, the annunciator flashes about once per second while pressing the
PTT, the COM MIC annunciator is no longer lit, and the active COM frequency for that Audio Panel changes to
white, indicating that there is no COM selected.
Figure 4-59 PA Key Selected for Cabin Announcements
PA Key is Selected on
the Audio Panel
SIMULTANEOUS COM OPERATION
Both the pilot and the copilot can transmit and receive simultaneously over separate COM radios. The
selected COM MIC Annunciator flashes when either pilot’s microphone PTT is pressed.
If both pilots select the same COM radio, the pilot has priority on COM1 and the copilot has priority on
COM2.

Garmin G1000 Specifications

General

Display Type	LCD
Primary Flight Display (PFD)	Yes
Multi-Function Display (MFD)	Yes
Terrain Awareness	Yes
Autopilot Integration	Yes
Integrated Flight Deck System	Yes
Weather Radar	Optional
Traffic Advisory System (TAS)	Optional
Terrain Awareness and Warning System (TAWS)	Yes
Resolution	1024 x 768 pixels
Weather Data	Yes
Navigation	Yes
AHRS	Yes
Air Data Computer (ADC)	Yes
Interfaces	ARINC 429, RS-232
Certification	TSO certified
Traffic Information	Optional (requires ADS-B or TCAS)
