Garmin G1000 Guide

190-00709-05 Rev. D
Garmin G1000 Pilot’s Guide for the Socata TBM 850/900
167
AUDIO PANEL AND CNS
PFD FAILURE
If PFD1 fails, COM1 and NAV1 display a red X on both remaining displays. NAV1 is unavailable. COM1
automatically tunes 121.500 MHz, but the frequency is not shown. The COM1 emergency frequency is available
to both the copilot and pilot.
Figure 4-65 Frequency Section of PFD2 Display after PFD1 Failure
Emergency Channel
Loaded Automatically
If PFD2 fails, COM2 and NAV2 display a red X on the remaining PFD display. NAV2 is unavailable. COM2
tunes 121.500 MHz, but the frequency is not shown. The COM2 emergency frequency is available to both the
copilot and pilot.
Figure 4-66 PFD1 Display after PFD2 Failure

Garmin G1000 Specifications

General

Display Type	LCD
Primary Flight Display (PFD)	Yes
Multi-Function Display (MFD)	Yes
Terrain Awareness	Yes
Autopilot Integration	Yes
Integrated Flight Deck System	Yes
Weather Radar	Optional
Traffic Advisory System (TAS)	Optional
Terrain Awareness and Warning System (TAWS)	Yes
Resolution	1024 x 768 pixels
Weather Data	Yes
Navigation	Yes
AHRS	Yes
Air Data Computer (ADC)	Yes
Interfaces	ARINC 429, RS-232
Certification	TSO certified
Traffic Information	Optional (requires ADS-B or TCAS)
