190-00709-05 Rev. D Garmin G1000 Pilot’s Guide for the Socata TBM 850/900 140
AUDIO PANEL AND CNS
NAV radios are selected for listening by pressing the corresponding keys on the Audio Panel. Pressing the
NAV1, NAV2, ADF, or DME Key selects and deselects the navigation radio source. Selected audio can be heard over
the headset and the speakers (if selected). All radios can be selected individually or simultaneously.
Figure 4-29 Selecting a NAV Radio Receiver
NAV RECEIVER MANUAL TUNING
The NAV frequency controls and frequency boxes are on the left side of the PFDs.
Manually tuning a NAV frequency:
1) Turn the NAV Knob to tune the desired frequency in the NAV Tuning Box.
2) Press the Frequency Transfer Key to transfer the frequency to the NAV Active Frequency Field.
3) Adjust the volume level with the NAV VOL/ID Knob .
4) Press the NAV VOL/ID Knob to turn the Morse code identifier audio on and off.
Figure 4-30 NAV Frequency Tuning
Press the
Frequency Transfer Key to
Transfer NAV Frequencies Between
Active and Standby Frequency Fields
Turn the
NAV Knob to
Tune the Frequency in
the Tuning Box
Turn VOL/ID Knob to adjust
volume. Press Knob to Turn
Morse Code On or Off.

Garmin G1000 Specifications

General

Display Type	LCD
Primary Flight Display (PFD)	Yes
Multi-Function Display (MFD)	Yes
Terrain Awareness	Yes
Autopilot Integration	Yes
Integrated Flight Deck System	Yes
Weather Radar	Optional
Traffic Advisory System (TAS)	Optional
Terrain Awareness and Warning System (TAWS)	Yes
Resolution	1024 x 768 pixels
Weather Data	Yes
Navigation	Yes
AHRS	Yes
Air Data Computer (ADC)	Yes
Interfaces	ARINC 429, RS-232
Certification	TSO certified
Traffic Information	Optional (requires ADS-B or TCAS)
