HAZARD AVOIDANCE
Mode
Traffic Mode Annunciation
(Traffic Map Page)
Traffic Display Status Icon
(Other Maps)
TAS System Test
Initiated
TEST
(also shown in white in center of page)
TAS Operating OPERATING
TAS Standby
STANDBY
(also shown in white in center of page)
TAS Failed* FAIL
* See Table 6-36 for additional failure annunciations
Table 6-35 TAS Modes
If the traffic unit fails, an annunciation as to the cause of the failure is shown in the center of the Traffic Map
Page. During a failure condition, the Operating Mode cannot be selected.
Traffic Map Page
Annunciation
Description
NO DATA Data is not being received from the TAS unit
DATA FAILED
Data is being received from the TAS unit, but the
unit is self-reporting a failure
FAILED Incorrect data format received from the TAS unit
Table 6-36 TAS Failure Annunciations
The annunciations to indicate the status of traffic information appear in a banner at the lower left corner of
maps on which traffic can be displayed.
Traffic Status Banner
Annunciation
Description
TA OFF SCALE
A Traffic Advisory is outside the selected display range*.
Annunciation is removed when traffic comes within the
selected display range.
TA X.X ± XX ↕
System cannot determine bearing of Traffic Advisory**.
Annunciation indicates distance in nm, altitude separation
in hundreds of feet, and altitude trend arrow (climbing/
descending).
TRFC FAIL
TAS unit has failed (unit is self-reporting a failure or
sending incorrectly formatted data)
NO TRFC DATA Data is not being received from the TAS unit
*Shown as symbol on Traffic Map Page
**Shown in center of Traffic Map Page
Table 6-37 TAS Traffic Status Annunciations
