MDE-5411A ForeHB Islander Prime Installation Manual · October 2018 Page 19
3.7 Technical Specifications and Standards System Overview
3.7 Technical Specifications and Standards
The following details the technical specifications, as well as the communication and security
standards for the Islander Prime.
3.7.1 Islander Prime Technical Specifications
The following details the physical, electrical, and environmental specifications of the Islander
Prime (see Table 2):
Table 2: Islander Prime Technical Specifications
Parameter Value
Dimensions (H x W x D) Standard: 158 x 30 x 29 cm |
62.2-inch x 11.8-inch x 29.2-inch in.
ADA accessible: 128 x 30 x 29 cm | 50-inch
x 11.8-inch x 29.2-inch.
Supply Voltage 100 - 240 VAC
Power Consumption 2A max
Operating Temperature Without Printer:
-40° to +65°C | -40° to +149°F
With Printer: -
40° to +50°C | -40° to +122°F
With Barcorde:
-30° to +60°C | -22° to +140°F
Storage Temperature -40° to +70°C | -40° to +158°F
Humidity 80% Non-condensing
Communication Interface • RS-485
• RS-232
• RS-422
•LAN
Pump Communication Interface • RS-485
•RS-422
• Current Loop
•MPI-C
• Tokheim
Wireless Communication Optional wireless communication IEEE802.15.4 with proprietary mesh
netwo
rk (License)
Pump Control Maximum Current
(4 Solid State Relay Channels)
Maximum of 380mA current for each channel, either
for driving the external
relay of the pump motor or for driving the solenoid valve
Power supply output voltage to Pulser
unit
12 VDC +/- 20% 50mA
Power Supply Maximum Output
Cur
rent
8 A max
Pulser Input High level Voltage 9 to 15 VDC
Pulser Input Low level sink current
(@
15V)
3mA max.
In use “On” level (Input) 100 – 240 VAC, 50/60 Hz, 5mA
In use “Off” level (Input) 0 to 10 VAC
Certifications ETL, CE, FCC, cETLus
Optional Accessories • Printer
• EMV Card Reader and Payment
• Insert Card Reader
• HID Card Reader
• Barcode Reader
• ADA (Americans with Disabilities Act
) Pedestal
• Stainless Steel Pedestal
