MDE-5411A ForeHB Islander Prime Installation Manual · October 2018 Page 39
5.3 Installing the Pedestal Base Installation
5.3.1 Installation Procedure
Installation of the Islander Prime pedestal consists of the following general steps:
• Running conduits to the pedestal site
• Installing the base plate
• Installing the pedestal base
• Installing the pedestal
• Running the cable conduits to the installation hole and
filling all open holes
5.3.2 Preliminary Setup
To perform the preliminary setup procedures for the pedestal site, proceed as follows:
1 Determine the exact location for the Islander Prime pedestal installation.
2 Run cable conduits for each type of cables to the Islander Prime location:
• One High Voltage conduit from the dispenser
• One Low Voltage conduit from the dispe
nser
• One Low Voltage conduit from the office
• One High Voltage conduit from the Mains Distribution Box
3 Run the cable conduits to the hole.
Notes:1) All conduits must be seal
ed when the unit is installed.
2) Ensure that the conduits are the right length to
reach above the pedestal base into the
pedestal itself. Various pedestal base heights are available; refer to the specifications
of the configuration that you have ordered to determine how far the conduits must
reach.
5.3.3 Assembly Parts
The following table lists the assembly parts required for the Islander Prime installation
(see Table 7):
Table 7:
Item No. Description Qty P/N
1 Bolt, ICU 4 814904200
2 Nut, M10 8 815103000
3 Washer, Flat, SM10 8 815300200
4 Base plate 1 814353700
Islander Prime Assembly Parts
