Preliminary Guidelines 4.6 Power Setup
Page 32 MDE-5411A ForeHB Islander Prime Installation Manual · October 2018
4.5.1 Cable Types
The following are the types of cables used for the wiring of the Islander Prime system 
(see Table 4):
Table 4:
No. Function Type
1 AC Power from
Of
fice
Power cable, 3x1.5 mm
2
0.118 x 0.06-inch
2
/ NYY (14 AWG), in accordance with local
standards.
Control to pumps
(
valves or engine)
In-use signal
2 Coil (Barrier) Data communication cable, 300 V RMS, 90°C /194°F, shielded twisted pair, oil resistant, 24
A
WG, low capacitance below 60 PF/meter (3.3') similar to Belden 9729 cable.
Pulser
TLG (RS-232)
3 LAN CAT5E, Shielded, 300 V RMS, 90°C/194°F similar to Belden 121700A.
4 GND Ground cable 0.4-inch (10.8-mm
2
).
Islander Prime Cable Types
4.5.2 Cable Routing
Route the cables from the peripherals and the office to Islander Prime as shown below 
(see Table 5):
Table 5: Islander Prime Cable Routing
No. Functional Description From Through Insert Cable Type
1 Power AC Office High voltage conduit 1
2 GND Office High voltage conduit 4
3 TLG Office Low voltage conduit 2
4 LAN Office Low voltage conduit 3
5 Control, Pump A Pump A High voltage conduit 1
6 In-use, Pump A Pump A High voltage conduit 1
7 GND Pump A Low voltage conduit 2
Note: The cable type number refers to the table in the above section (see Table 4).
4.6 Power Setup
The power equipment must be installed in the main power cabinet. It should include the
following:
• Mains Circuit Control (MCC) Box includes dedic
ated circuit breaker for the pedestal
• Uninterruptible Power Supply (UPS) -
Online (“True”) UPS
