Gasboy Islander Prime User Manual

Installation 5.4 Installing Options
Page 46 MDE-5411A ForeHB Islander Prime Installation Manual · October 2018
To install an HID Reader in the Islander Prime, proceed as follows:
1 Remove the screws affixing the HID Bracket to the Islander Prime pole door.
2 Remove the back plate from the HID Reader.
3 Fasten the HID Reader back plate to the HID Bracket using the flat head screws provided in
the installation kit as follows (see Figure 27).
Figure 27: HID Reader Back Plate
4 Pull the HID connector harness cable through the HID bracket, and mount the HID Reader to
the bracket as follows (see Figure 28).
Figure 28: HID Reader on Back Plate
