Machine Setting- Scaling Page
The Scaling Page allows you to fine tune the laser machine output scale to precisely fit the original
graphic file design scale when precision output is requried to your application.
Please reboot the machine after clicking <Save> button for the change.
Scaling Page
Relevant Buttons
Function
Back
Back to previous page
Save
Save your current settings
 /  Directional
Adjust the X axis scaling numbers
 /  Directional
Adjust the Y axis scaling numbers
Navigating to this page:
Main Work Page
Functions Page
Machine Setting Page
Scaling Page
