• Top To Bottom: Selecting this will force the system to process the current task by moving the lens
carriage from the top to the bottom of the image (rear end to front end of the work table).
• Bottom To Top: Selecting this will force the system to process the current task by moving the lens
carriage from the bottom to the top of the image (front end to rear end of the work table)
Normally, the LaserPro S400 engraves from left to right, top to bottom. Selecting Bottom Up will
alter the engraving sequence and the engraving will start from the bottom and work its way to the
rear of the working table.
T
i
p
In situations where the material you will be working with may produce a lot of
dust byproducts and you are utilizing the optional air extraction system, it is
recommended that you select the Bottom To Top image output direction option.
This will minimize the amount of dust byproducts lodged in the engraved
sections as the air extraction system is vented from the rear of the machine, the
same direction as the image is processed.
Border (Advanced Page) [DEFAULT SETTING: Unselected]
In cases where you are working with a negative image (negative outline areas of your image are
engraved, rather than the positive areas), you may wish to include a border around your image.
To properly add a border, you will first need to Invert your design from the Options Page, then
check Use Border and specify a value for the thickness of the border you would like to add to
your design. This mode is useful for engraving rubber stamps, as it allows you to create the
outline around your stamp image.
If you wish to use the Border and Cluster function simultaneously, the Border
Thickness value must be less than the Distance value specified in the Cluster setting.
