15. SR-1000 INPUT AND OUTPUT
A Microphone can be connected to the MIC. IN on the
front panel of the AIB-2000 using a Male XLR
Connector.
If the microphone requires Phantom power, then press
the +48V button.
Connecting a Non-Sync source
*
A Non-sync source can be connected to the NON-SYNC
IN on the front panel of the AIB-2000 using Male XLR
connectors or to the NonSync IN on the back panel
using Male stereo RCA Connectors.
NON-SYNC front/back button switches NonSync input
between front XLR and rear RCA Connectors.
Connecting an HDMI source
An HDMI source can be connected to the HDMI IN on
the faceplate of the SR-1000, using an HDMI cable.
Connecting a Booth Monitor
*
A Booth monitor can be connected to the LCR mon
output on the back panel of the AIB-2000 using an RCA
Connector.
Please note that the LCR mon output provides a L+C+R
summation of the AES3 outputs from the SR-1000.
* Refer to the ‘AIB-2000 Manual’ for more details.
IMPORTANT: Please check and set the levels of the analog input sources to the AIB-
2000 appropriately, to avoid any damage to the auditorium speakers.
