15. SR-1000 INPUT AND OUTPUT
15.6.1.1 Connections Requirements
Sr. No.
Device Type
Description
1
Connection to analog Amplifier
*
Connect the 8-channel Analog unbal. output of the
AIB-2000 to the inputs of analog Amplifiers/Crossovers
using appropriate line level audio cables and connectors.
2
Connection to Hi/Vi-N devices
AES output pair 11 and 12 on the SR-1000 carries the
Hi and Vi-N channels respectively (assuming DCP’s
follow the 16-channels ISDCF recommended channel
order).
The AES pair 11/12 is available on the RJ45 Connector
labeled A-bot on the IMB and can be connected to the
Hi/Vi-N device either directly or via a 2 channel D/A
converter depending on whether the Hi/Vi-N device
accepts AES3 or analog inputs.
Appropriate cable and connectors should be chosen,
keeping in mind the connectors used on the Hi/Vi-N
device and 2-channel D/A converter (if used).
3
Connection to 4D systems
AES output pair 15 and 16 on the SR-1000 carries the
LTC signal used to sync 4D systems like ScreenX, 4DX
and MX4D to the SR-1000.
Note: The ‘Enable LTC Output on Channel 15/16’ option
must be checked.
The AES pair 15/16 is available on the RJ45 Connector
labeled A-bot on the IMB and can be connected to the
LTC input on the 4D System.
Appropriate cable and connectors should be chosen
keeping in mind the connector used on the 4D system.
4
Connection to D-Box
AES output 13 on the SR-1000 carries the Motion Data
signal used by D-Box (assuming DCPs follow the 16-
channels ISDCF recommended channel order).
The AES pair 13/14 is available on the RJ45 Connector
labeled A-bot on the IMB and can be connected to the D-
Box system. Appropriate cable and connectors should be
chosen keeping in mind the connector used on the D-Box
system.
