INSTALLATION MANUAL FOR SR-1000
STANDALONE INTEGRATED MEDIA BLOCK™
User Manual
15. SR-1000 INPUT AND OUTPUT
A Microphone can be connected to the MIC. IN on the
front panel of the AIB-2000 using a Male XLR
Connector.
If the microphone requires Phantom power, then press
the +48V button.
Connecting a Non-Sync source
*
A Non-sync source can be connected to the NON-SYNC
IN on the front panel of the AIB-2000 using Male XLR
connectors or to the NonSync IN on the back panel
using Male stereo RCA Connectors.
NON-SYNC front/back button switches Non-Sync input
between front XLR and rear RCA Connectors.
Connecting an HDMI source
An HDMI source can be connected to the HDMI IN on
the faceplate of the SR-1000, using an HDMI cable.
Connecting a Booth Monitor
*
AES pair 9/10 on the SR-1000 carries a mix of L+C+R
which can be used as a monitor output.
The AES pair 9/10 is available on the RJ45 Connector
labeled A-bot on the IMB and can be connected to the
Booth monitor via a D/A Converter.
* Refer to the ‘AIB-2000 User Manual’ for more details.
IMPORTANT: Please check and set the levels of the analog input sources to the AIB-
2000 appropriately, to avoid any damage to the auditorium speakers.
