13-6 ALPS Advanced Line Protection System
GE Power Management
13.2 XPRESSION BUILDER FLAGS 13 XPRESSION BUILDER
13
Table 13–5: SCHEME LOGIC INPUTS
INDEX DESCRIPTION MNEMONIC
1 Breaker #1 52b Contact Input 52B_1
4 Breaker #2 52b Contact Input 52B_2
8 Chan
g
e Settin
g
Group Input Bit 0 CGST1
9 Chan
g
e Settin
g
Group Input Bit 1 CGST2
10 External Contact Input to Stop Carrier STCR
11 External Contact Input to Block Pilot Trippin
g
BPLTRP
12 Receiver 1 Input RCVR1
13 Receiver 2 Input RCVR2
15 External Reclose Initiate 3-Pole EXRI3P
16 External Reclose Inhibit EXRINH
17 External Reclose Cancel EXRCNL
18 Reclose Reset RCLRST
19 External Manual Close EMNCLS
20 External Contact to Reset Trip Tar
g
et Display RESET
21 External Contact Input to Disable Protection DISPRT
22 External Contact Input to Disable Outputs DISOUT
23 External Contact to Tri
gg
er Oscillo
g
raphy OSCTRG
24 Manual Lock-Out MANLKT
Table 13–6: DISTANCE UNITS (Sheet 1 of 2)
INDEX DESCRIPTION MNEMONIC
65 Zone 1 AB Distance Function Z1AB
66 Zone 1 BC Distance Function Z1BC
67 Zone 1 CA Distance Function Z1CA
68 Zone 2 AB Distance Function Z2AB
69 Zone 2 BC Distance Function Z2BC
70 Zone 2 CA Distance Function Z2CA
71 Zone 3 AB Distance Function Z3AB
72 Zone 3 BC Distance Function Z3BC
73 Zone 3 CA Distance Function Z3CA
74 Zone 4 AB Distance Function Z4AB
75 Zone 4 BC Distance Function Z4BC
76 Zone 4 CA Distance Function Z4CA
77 Any Zone 1 Phase Distance Function Z1PH
78 Any Zone 2 Phase Distance Function Z2PH
79 Any Zone 3 Phase Distance Function Z3PH
80 Any Zone 4 Phase Distance Function Z4PH
81 Zone 1 AG Distance Function Z1AG
82 Zone 1 BG Distance Function Z1BG
83 Zone 1 CG Distance Function Z1CG
84 Zone 2 AG Distance Function Z2AG
85 Zone 2 BG Distance Function Z2BG
86 Zone 2 CG Distance Function Z2CG
87 Zone 3 AG Distance Function Z3AG
88 Zone 3 BG Distance Function Z3BG
89 Zone 3 CG Distance Function Z3CG
