GE Power Management
ALPS Advanced Line Protection System 13-7
13 XPRESSION BUILDER 13.2 XPRESSION BUILDER FLAGS
13
90 Zone 4 AG Distance Function Z4AG
91 Zone 4 BG Distance Function Z4BG
92 Zone 4 CG Distance Function Z4CG
93 Any Zone 1 Ground Distance Function Z1GRD
94 Any Zone 2 Ground Distance Function Z2GRD
95 Any Zone 3 Ground Distance Function Z3GRD
96 Any Zone 4 Ground Distance Function Z4GRD
129 Zone 2 Ground Timer Z2GTMR
130 Zone 3 Ground Timer Z3GTMR
131 Zone 4 Ground Timer Z4GTMR
132 Zone 2 Phase Timer Z2PTMR
133 Zone 3 Phase Timer Z3PTMR
134 Zone 4 Phase Timer Z4PTMR
106 TL1 Timer Output TL1
124 TL16 Timer Output TL16
125 TL24 Timer Output TL24
128 TL25 Timer Output TL25
126 Ground Forward Fla
g
(NT) GRDFWD
127 Ground Reverse Fla
g
(NB) GRDREV
Table 13–7: CURRENT AND VOLTAGE UNITS
INDEX DESCRIPTION MNEMONIC
103 Any Phase Undervolta
g
e ANYUVT
104 All Volta
g
e Hi
g
h (No Phase Undervolta
g
e) ALLVLT
105 Fault Detector (FD) FLTDET
107 IT Detector IT
108 IB Detector IB
109 IPT Detector IPT
110 IPB Detector IPB
111 Remote Breaker Open Detector REMOPN
112 Ground Directional Trip (NT AND IPT) GRDTRP
113 Ground Directional Block (NB AND IPB) GRDBLK
116 Instantaneous Phase Overcurrent (50P/PH4) 50
117 Instantaneous Ground Overcurrent (50G/IDT) 50G
118 Ground Time Overcurrent Pick-Up TOCACT
119 Ground Time Overcurrent Trip (51G/TOC) TOCTRP
Table 13–6: DISTANCE UNITS (Sheet 2 of 2)
INDEX DESCRIPTION MNEMONIC
