13-8 ALPS Advanced Line Protection System
GE Power Management
13.2 XPRESSION BUILDER FLAGS 13 XPRESSION BUILDER
13
Table 13–8: MISCELLANEOUS
INDEX DESCRIPTION MNEMONIC
137 Sync Check SYNC
138 Number of Breaker Operation Alarm BRMNOP
139 Breaker Equipment Duty Alarm BRMNDT
60 Fault ID: Phase A Involved DAFLTA
61 Fault ID: Phase B Involved DAFLTB
62 Fault ID: Phase C Involved DAFLTC
63 Fault ID: Neutral Involved DAFLTN
64 DMA Overrun DMAOVR
147 Trip Circuit #1 Volta
g
e Monitor Status T1TC
148 Trip Circuit #2 Volta
g
e Monitor Status T2TC
149 Trip Circuit #3 Volta
g
e Monitor Status T3TC
150 Trip Circuit #4 Volta
g
e Monitor Status T4TC
Table 13–9: USER DEFINABLE OUTPUT FLAGS
INDEX DESCRIPTION MNEMONIC
- Trip Contacts T1 to T6
- Auxiliary Contacts A1 to A12
- Control Contacts C1 to C2
-Hi
g
h Speed Channel Contacts KT1 to KT4
- User Defined Trip CONFTRIP
- User Defined Oscillo
g
raphy Capture CONFOSC
- User Defined Non-Critical Alarm NC Alarm
