B-10 ALPS Advanced Line Protection System
GE Power Management
B.2 REGISTER MAPS APPENDIX B
B
3248 IPT_PICKUP R/W P100 1 10 to 500 50 to 2500 A 15 75
3249 IPB_PICKUP R/W P100 1 5 to 75 25 to 375 A 5 25
3250 IPBKFACTOR R/W Unsi
ned Int 1 0 = 0.0; 1 = 0.066 - 1
3251 NT_OFFSET R/W P100 1 0 to 100 Ω 0.25 0.05
3252 UNBALALARM R/W Unsi
ned Int 1 0=No, 1=Yes - 1
PROTECTION SETTINGS: OVERCURRENT
3253 50 R/W Unsi
ned Int 1 0=No, 1=Yes - 0
3254 50_DIRCNL R/W Unsi
ned Int 1 0=No, 1=Yes - 1
3255 50PICKUP R/W P10 1 4 to 320 20 to 1600 A 40 200
3256 50PICKUPFF R/W Float 1 4 to 320 20 to 1600 A 60 300
3257 50G R/W Unsi
ned Int 1 0=No, 1=Yes - 1
3258 50G_DIRCNL R/W Unsi
ned Int 1 0=No, 1=Yes - 1
3259 50GPICKUP R/W P10 1 1 to 160 5 to 800 A 20 100
3260 50GPICKUPFF R/W P10 1 1 to 160 5 to 800 A 60 300
3261 50GRESTNT R/W Unsi
ned Int 1 0 = 0.0; 1 = 0.3 - 1
3262 51G R/W Unsi
ned Int 1 0=No, 1=Yes - 1
3263 51G_DIRCNL R/W Unsi
ned Int 1 0=No, 1=Yes - 1
3264 51GPICKUP R/W P100 1 4 to 300 20 to 1500 A 20 100
3265 51GPICKUPFF R/W P100 1 4 to 300 20 to 1500 A 40 200
3266 51GCURVE R/W Unsi
ned Int 1 0=Inv, 1=V-Inv, 2=E-Inv,
3=Custom, 4=DefT
-1
3267 51GTIMDIAL R/W P10 1 5 to 100 - 50
3268 DEFTIMDELY R/W P10 1 5 to 300 sec. 10
3269 51G_RESET R/W Unsi
ned Int 1 0 = Fast, 1 = EM - 0
PROTECTION SETTINGS: VOLTAGE
3270 RATEDVOLTS R/W Unsi
ned Int 1 100, 105, 110, 115, 120 V 115
3271 PHASEOVER R/W Unsi
ned Int 1 0=No, 1=Yes - 0
3272 PHOVPICKUP R/W P100 1 0 to 140 pu V 1
3273 PHOVTMDLY R/W P100 1 0 to 1000 sec. 50
3274 V1OVER R/W Unsi
ned Int 1 0=No, 1=Yes - 0
3275 V1OVINSTPU R/W P100 1 100 to 140 pu V 125
3276 V1OVTIMPU R/W P100 1 100 to 140 pu V 125
3277 V1OVTIMDLY R/W P100 1 0 to 1000 sec. 25
3278 V1COMP R/W Unsi
ned Int 1 0=No, 1=Yes - 0
3279 V1COMPRCH R/W P100 1 5 to 25000 1 to 5000 Ω 3000 600
3280 V1COMPINPU R/W P100 1 100 to 140 pu V 140
3281 V1COMPTDPU R/W P100 1 100 to 140 pu V 140
3282 V1COMPTDLY R/W P100 1 0 to 1000 sec. 150 30
3283 FUSEFAIL R/W Unsi
ned Int 1 0=No, 1=Yes - 1
PROTECTION SETTINGS: BLOCK RECLOSING
3284 ALL_BELOW R/W Unsi
ned Int 1 0=No, 1=Yes - 0
3285 OUTOFSTEP R/W Unsi
ned Int 1 0=No, 1=Yes - 0
3286 ALL_3_Z2PH R/W Unsi
ned Int 1 0=No, 1=Yes - 0
3287 50G_BLOCK R/W Unsi
ned Int 1 0=No, 1=Yes - 0
3288 Z2TIMETRIP R/W Unsi
ned Int 1 0=No, 1=Yes - 0
3289 Z3TIMETRIP R/W Unsi
ned Int 1 0=No, 1=Yes - 0
Table B–4: MODBUS MEMORY MAP (Sheet 6 of 10)
ALPS
REGISTER
CONTENTS TYPE FORMAT NO. OF
REGS.
RANGE UNITS DEFAULT
1A 5A 1A 5A
1, 2, 3, 4, 5, 6, 7, 8
See pa
e B–14 for footnote explanations.
