B.2 REGISTER MAPS APPENDIX B
B
MEMORY MAP FOOTNOTES:
1. Valid for single-pole models only.
2. Valid only when blocking scheme is selected.
3. Valid only for models with recloser.
4. Specific to each serial interface.
5. Valid for models with rear serial port only.
6. Valid for single-pole and LPS models only.
7. Valid for models with series compensation only.
8. Valid for models with positive-sequence overvoltage only.
9. Valid for three-pole models only
3410 A7 R/W Unsigned Int 1 0 to 256 - 38
3411 A8 R/W Unsigned Int 1 0 to 256 - 45
3412 A9 R/W Unsigned Int 1 0 to 256 - -
3413 A10 R/W Unsigned Int 1 0 to 256 - -
3414 A11 R/W Unsigned Int 1 0 to 256 - -
3415 A12 R/W Unsigned Int 1 0 to 256 - -
3416 C1 R/W Unsigned Int 1 0 to 256 - 52
3417 C2 R/W Unsigned Int 1 0 to 256 - 115
3418 KT1 R/W Unsigned Int 1 0 to 256 - 39
3419 KT2 R/W Unsigned Int 1 0 to 256 - 40
3420 KT3 R/W Unsigned Int 1 0 to 256 - 39
3421 KT4 R/W Unsigned Int 1 0 to 256 - 40
3422 CONFTRIP R/W Unsigned Int 1 0 to 40 0 to 256 - - -
3423 CONFOSC R/W Unsigned Int 1 0 to 40 0 to 256 - - -
3424 Reserved RO - - - - - - -
↓↓
RO - - - - - - -
3499 Reserved RO - - - - - - -
SETTINGS REGISTERS GROUP 2
3500 Settings address equivalent to SETTINGS REGISTERS GROUP 1 plus 300. See registers 3200 to 3499 for details of the
individual registers.
↓
3799
SETTINGS REGISTERS GROUP 3
3800 Settings address equivalent to SETTINGS REGISTERS GROUP 1 plus 600. See registers 3200 to 3499 for details of the
individual registers
↓
4099
SETTINGS REGISTERS GROUP 4
4100 Settings address equivalent to SETTINGS REGISTERS GROUP 1 plus 900. See registers 3200 to 3499 for details of the
individual registers
↓
4399
REPORT CONTROL REGISTERS
4400 Report Control Register R/W Integer 1
XXYY , where X=0 (none – default) or 2 (Fault Report);
Y =01 to 36 (fault index, dependent on NUMFLTS setting)
Table B–4: MODBUS MEMORY MAP (Sheet 10 of 10)
ALPS
REGISTER
CONTENTS TYPE FORMAT NO. OF
REGS.
RANGE UNITS DEFAULT
1A 5A 1A 5A
1, 2, 3, 4, 5, 6, 7, 8
See page B–14 for footnote explanations.
