GE ALPS - Page 311

GE Power Management
ALPS Advanced Line Protection System B-17
APPENDIX B B.2 REGISTER MAPS
B
F22 2 bytes Digital Test Number
0 END OF TEST
1T1
2T2
3T3
4T4
5 T5 (1-phase trippin
g
model only)
6 T6 (1-phase trippin
g
model only)
7A1
8A2
9A3
10 A4
11 A5
12 A6
13 A7
14 A8
15 A9 (1-phase trippin
g
model only)
16 A10 (1-phase trippin
g
model only)
17 A11 (1-phase trippin
g
model only)
18 A12 (1-phase trippin
g
model only)
19 KT1
20 KT2
21 KT3
22 KT4
23 C1A/C1B
24 C2A/C2B
25 CA-A/B (Critical Alarm)
F26 2 bytes Output Mode
0 output enabled
1 Output disabled
F27 2 bytes Contact Converter Status Bits
(0=not activated, 1=activated)
bit 0 Status for CC1
bit1 Status for CC2
bit 2 Status for CC3
bit 3 Status for CC4
bit 4 Status for CC5
bit 5 Status for CC6
bit 6 Status for CC7
bit 7 Status for CC8
bit 8 Status for CC9 (1-phase model)
bit 9 Status for CC10 (1-phase model)
bit 10 Status for CC11 (1-phase model)
bit 11 Status for CC12 (1-phase model)
Table B–5: DATA FORMATS (Sheet 5 of 12)
TYPE VALUE/
BITMASK
DESCRIPTION
F28 2 bytes Output Contact Status Bits
(0=not activated, 1=activated)
bit 0 status for T1
bit 1 status for T2
bit 2 status for T3
bit 3 status for T4
bit 4 status for T5 (1-phase model)
bit 5 status for T6 (1-phase model)
bit 6 status for A1
bit 7 status for A2
bit 8 status for A3
bit 9 status for A4
bit 10 status for A5
bit 11 status for A6
bit 12 status for A7
bit 13 status for A8
bit 14 status for A9 (1-phase model)
bit 15 status for A10 (1-phase model)
bit 16 status for A11 (1-phase model)
bit 17 status for A12 (1-phase model)
bit 18 status for KT1
bit 19 status for KT2
bit 20 status for KT3
bit 21 status for KT4
bit 22 status for C1
bit 23 status for C2
bit 24 status for CA-A/B (Critical Alarm)
F43 2 bytes Reset Type
0 Fault report and oscillo
g
raphy data
1 Event Data
2OST Data
3 Breaker Health
4 Reset Tar
g
et LEDs, Clear Warn and
Fail and Trip Messa
g
e from Display
and EEPROM
F48 2 bytes Breaker Duty
0 to 9999 Actual Value
10000 to
19999
20000 to
29999
F49 2 bytes Multiplier
0 M - Millions
1 K - Thousands
2 Actual Value
F52 2 bytes PHASEROTATE value
0ABC
1ACB
Table B–5: DATA FORMATS (Sheet 6 of 12)
TYPE VALUE/
BITMASK
DESCRIPTION
Value 10000
–
10
--------------------------------------
10
3
×
Value 20000
–
10
--------------------------------------
10
6
×
