B.2 REGISTER MAPS APPENDIX B
B
F56 2 bytes Baud Rate
03 300
12 1200
24 2400
48 4800
96 9600
19 19200
F57 2 bytes Parity
0 no parity
1 odd parity
2 even parity
F58 2 bytes Stop bits
11
22
F59 2 bytes Interface
0 RS-232
1 RS-485
F60 2 bytes DISPLAYVAL value
0 Primary
1 Secondary
F61 2 bytes Event Codes
000 FAIL-CPU BOARD SRAM
001 FAIL-960 ACCESS TO DPRAM
002 FAIL-EEPROM
003 FAIL-DIGITAL OUTPUT TEST
004 FAIL-INTERRUPT TEST
005 FAIL-ANI ADC CONTROL LOGIC
006 FAIL-ANI REFERENCE CHANNEL
TEST
007 FAIL-DMA INTERRUPT
008 FAIL-ANI BOARD TIMER
009 FAIL-ANI BOARD SERIAL
EEPROM TEST
010 FAIL-MAG MODULE SERIAL
EEPROM TEST
011 FAIL-DIG OUTPUT SERIAL
EEPROM TEST
012 FAIL-DTA SERIAL EEPROM TEST
013 FAIL-DSP PROM
014 FAIL-DSP INTERNAL RAM
015 FAIL-DSP INTERNAL RAM
CHECKSUM ERROR
016 FAIL-DSP ACCESS TO DPRAM
017 FAIL-DSP INTERRUPT
018 FAIL-DIGITAL INPUT TEST
019 FAIL-MODEL NUMBER
020 FAIL-MAG MODULE CONFIG
MISMATCH
Table B–5: DATA FORMATS (Sheet 7 of 12)
TYPE VALUE/
BITMASK
DESCRIPTION
F61
ctd
021 FAIL-ANI MODULE CONFIG
MISMATCH
022 FAIL-DIG INPUT MODULE
CONFIG MISMATCH
023 FAIL-DIG OUTPUT MODULE
CONFIG MISMATCH
024 FAIL-TRIP CIRCUIT#1
CONTINUITY MONITOR
025 FAIL-TRIP CIRCUIT#2
CONTINUITY MONITOR
026 FAIL-TRIP CIRCUIT#3
CONTINUITY MONITOR
027 FAIL-TRIP CIRCUIT#4
CONTINUITY MONITOR
028 FAIL-TRIP CIRCUIT#5
CONTINUITY MONITOR
029 FAIL-TRIP CIRCUIT#6
CONTINUITY MONITOR
030 FAIL-SOFTWARE VERSION
ERROR
031 FAIL-DSP SOFTWARE VERSION
ERROR
032 FAIL-FIVE RESTARTS IN AN
HOUR
033 FAIL-i960-DSP INTERFACE
(DPRAM)
034 RUNTIME FLASH TEST CRC
CHECK FAIL
035 i960 INSTRUCTION FAULT
OCCURRED
036 i960 ARITHMETIC INSTRUCTION
FAULT
037 TOO MANY BOGUS INTERRUPTS
038 FAIL-DSP DPRAM CHECKSUM
039 to 42 NONE
043 WARN-CPU BOARD TIMER TEST
044 WARN-ZERO CROSSING LOGIC
045 WARN-CAPRAM FAILURE
046 WARN-RTC TEST FAILURE
047 WARN-COMM FRONT PORT
FAILURE
048 WARN-COMM REAR PORT 1
FAILURE
049 WARN-COMM REAR PORT 2
FAILURE
050 WARN-WATCHDOG TIMER
FAILED
051 WARN-LCD DISPLAY FAILURE
052 WARN - IRIGB FAILED
053 WARN - H/W MISMATCH - REAR
PORT2 ABSENT
054 WARN- NON CRIT FIELD IN
MODEL NUM ERROR
055 WARN - CAPRAM SIZE
MISMATCH
Table B–5: DATA FORMATS (Sheet 8 of 12)
TYPE VALUE/
BITMASK
DESCRIPTION
