Field replaceable units: Replace main unit parts
2000966-542D Dash 3000/4000/5000 7-39
8. If you installed the Nellcor OxiMax or Masimo SET SPO2 and 4 BP
SuperStat upgrade, place the labels as shown below.
9. Complete the procedures in “Recommended checkout” on page 7-52.
Masimo SET or
Nellcor OxiMax
827B
DINAMAP SUPERSTAT
BP 1/3 and BP 2/4
12SL (if software
option was enabled)
CO2, NBP, and ECG
NOTE
The BP 1/3 and BP 2/4 label looks similar to the example below.
860A
patent
disclosure label
004B
