GE Dash 4000 Service Manual

Introduction: Manual information
1-2 Dash 3000/4000/5000 2000966-542D
Manual information
Revision history
Each page of this manual has the document part number and revision
letter at the bottom of the page. The revision letter identifies the
document’s update level. The revision history of this document is
summarized below.
Manual purpose
This manual supplies technical information for service representatives
and technical personnel so they can maintain the equipment to the
assembly level. Use it as a guide for maintenance and electrical repairs
considered field repairable. Where necessary the manual identifies
additional sources of relevant information and technical assistance.
See the operator’s manual for the instructions necessary to operate the
equipment safely in accordance with its function and intended use.
Intended audience
This manual is intended for service representatives and technical
personnel who maintain, troubleshoot, or repair this equipment.
Ordering manuals
A paper copy of this manual will be provided upon request. Contact your
local GE representative and request the part number on the first page of
the manual.
Revision Comment
A Initial release of this manual.
B Updated WLAN a/b/g instructions.
C Added Appendix C - Network disclosure, updated Dash Port 2 software
compatibility, updated Windows workflows, and generalized disabling
firewall/network services workflows.
D Updated FRU kits.

GE Dash 4000 Specifications

General

Resolution	640 x 480 pixels
Power Supply	100-240 VAC, 50/60 Hz
ECG	3/5/12-lead
IBP	Up to 4 channels
Battery Backup	Yes
Certifications	CE, UL, CSA
Parameters Monitored	ECG, SpO2, NIBP, IBP, Temperature, Respiration, Cardiac Output
Connectivity	Ethernet, USB, Serial
Display Type	TFT LCD
Recorder	Integrated thermal printer
Battery Type	Lithium-ion
Operating Temperature	0 to 40°C
Storage Temperature	-20 to 60°C
Humidity Range	15% to 95% non-condensing
Display Size	10.4 inches
Cardiac Output	Available
