GE Dash 4000 Service Manual

Introduction: Service information
2000966-542D Dash 3000/4000/5000 1-9
Service information
Service requirements
Follow the service requirements listed below.
 Refer equipment servicing to GE-authorized service personnel only.
 Any unauthorized attempt to repair equipment under warranty voids
that warranty.
 It is the user’s responsibility to report the need for service to GE or to
one of their authorized agents.
 Failure on the part of the responsible individual, hospital, or
institution using this equipment to implement a satisfactory
maintenance schedule may cause undue equipment failure and
possible health hazards.
 Regular maintenance, irrespective of usage, is essential to ensure
that the equipment will always be functional when required.
Equipment identification
Every GE device has a unique serial number for identification. A sample
of the information found on a serial number label is shown below.
Description
A
product code
1
1. The current Dash patient monitor product code is SHQ.
Dash 3000/4000/5000 patient monitors with the
SHQ product code are only compatible with software
version 6.10 or later.
B year manufactured
C fiscal week manufactured
D production sequence number
E manufacturing site
F miscellaneous characteristic
### ## ## #### # #
ABCDEF

GE Dash 4000 Specifications

General

Resolution	640 x 480 pixels
Power Supply	100-240 VAC, 50/60 Hz
ECG	3/5/12-lead
IBP	Up to 4 channels
Battery Backup	Yes
Certifications	CE, UL, CSA
Parameters Monitored	ECG, SpO2, NIBP, IBP, Temperature, Respiration, Cardiac Output
Connectivity	Ethernet, USB, Serial
Display Type	TFT LCD
Recorder	Integrated thermal printer
Battery Type	Lithium-ion
Operating Temperature	0 to 40°C
Storage Temperature	-20 to 60°C
Humidity Range	15% to 95% non-condensing
Display Size	10.4 inches
Cardiac Output	Available
