GE Dash 4000 Service Manual

Network disclosure to facilitate network risk management:
C-6 Dash 3000/4000/5000 2000966-542D
Potential risks to safety, effectiveness or security resulting from
failure of IT network to provide the required characteristics
WARNING
Connection of the Dash patient monitor to a network that
includes other equipment could result in other
unidentified risks to patients, operators or third parties.
The responsible organization should identify, analyze,
evaluate and control these risks on an ongoing basis
including after changes to the network such as those
listed below, which could introduce new risks and require
additional analysis.
 Changes in network configuration.
 Connection of additional items to the network.
 Disconnecting items from the network.
 Update of equipment connected to the network.
 Upgrade of equipment connected to the network.

GE Dash 4000 Specifications

General

Resolution	640 x 480 pixels
Power Supply	100-240 VAC, 50/60 Hz
ECG	3/5/12-lead
IBP	Up to 4 channels
Battery Backup	Yes
Certifications	CE, UL, CSA
Parameters Monitored	ECG, SpO2, NIBP, IBP, Temperature, Respiration, Cardiac Output
Connectivity	Ethernet, USB, Serial
Display Type	TFT LCD
Recorder	Integrated thermal printer
Battery Type	Lithium-ion
Operating Temperature	0 to 40°C
Storage Temperature	-20 to 60°C
Humidity Range	15% to 95% non-condensing
Display Size	10.4 inches
Cardiac Output	Available
