GE Dash 4000 Service Manual

Configuration: Service menus
2000966-542D Dash 3000/4000/5000 4-3
Service menus
There are two distinct service menus for the patient monitor. The Boot
Loader Service Menu is found in the Boot Code and is used for
configuring the patient monitor or when downloading the Boot Code and
main processor code. The Service Mode menu is located from the Main
Menu and is used for various functions like monitor settings, calibration,
graph tests, and downloading patient monitor interface software.
WARNING
The Boot Loader Service Menu and the Service Mode
menus are intended for qualified personnel only. Do not
‘experiment’ with any commands found in the service
menus. Experimenting with service commands can lead
to lost patient data, damaged operating system software
for the patient monitor, and even affect the CARESCAPE
Network.

GE Dash 4000 Specifications

General

Resolution	640 x 480 pixels
Power Supply	100-240 VAC, 50/60 Hz
ECG	3/5/12-lead
IBP	Up to 4 channels
Battery Backup	Yes
Certifications	CE, UL, CSA
Parameters Monitored	ECG, SpO2, NIBP, IBP, Temperature, Respiration, Cardiac Output
Connectivity	Ethernet, USB, Serial
Display Type	TFT LCD
Recorder	Integrated thermal printer
Battery Type	Lithium-ion
Operating Temperature	0 to 40°C
Storage Temperature	-20 to 60°C
Humidity Range	15% to 95% non-condensing
Display Size	10.4 inches
Cardiac Output	Available
