Configuration: Service menus
2000966-542D Dash 3000/4000/5000 4-5
Main menu service mode
The Service Mode menu option items provide the service technician
access to general and technical built-in software functions of the patient
monitor. Only persons responsible for configuring and maintaining the
patient monitor should access the service mode menu option items.
The service technician can use the Service Mode menu to:
relay software information to design engineers,
calibrate and troubleshoot NBP functions of the patient monitor,
set admit menu options, operating mode of the patient monitor, and
monitor default password,
configure the patient monitor unit name, bed number and Internet
address for use on the network, and
enter or change the time and date on the patient monitor.
WARNING
The Boot Loader Service Menu and the Service Mode
menus are intended for qualified personnel only. Do not
‘experiment’ with any commands found in the service
menus. Experimenting with service commands can lead
to lost patient data, damaged operating system software
for the patient monitor, and even affect the CARESCAPE
Network.
Access the Service Mode
Access the Service Mode menu starting from the Main menu.
1. Select MORE MENUS > MONITOR SETUP > SERVICE MODE >
2. Enter password using the Trim Knob control to select the day and
month from patient monitor screen with leading zeros. (e.g. July 4 =
0407).
