Field replaceable units: Remove or replace display assembly
7-20 Dash 3000/4000/5000 2000966-542D
5. To prevent damaging the display flex cable, position the display
assembly for the patient monitor you are servicing.
Flex cable folds over
from the right side of
the display assembly.
870A
Metallic display
shield
1-inch
(2.54 cm)
830A
Dash 3000 display assembly with circuit board display shield
