GE Dash 4000 Service Manual

Introduction: Equipment symbols
2000966-542D Dash 3000/4000/5000 1-7
This symbol indicates the date of manufacture of this device. The first four digits identify the
year and the last two digits identify the month.
Non-ionizing electromagnetic radiation: To indicate elevated, potentially dangerous, levels
of non-ionizing radiation. Note - In case of application in a warning sign the rules according
to ISO 3864-1 shall be adhered to.
IEC 60878 note: See safety sign ISO 7010 - W005 “Warning, non-ionizing radiation”.
FCC. USA only. Complies with applicable US government (Federal Communications
Commission) radio-frequency interference regulations.
Manufacturer name and address.
Device serial number.
Russia only. GOST-R certification, where XXXX indicates the four-digit certification body
number determined by product.
Catalog or orderable part number.
European authorized representative.
Prescriptive device. USA only. For use by or on the order of a physician, or persons
licensed by state law.
CAUTION — Safety ground precaution. Remove power cord from the mains source by
grasping the plug. Do not pull on the cable.
2005-08

GE Dash 4000 Specifications

General

Resolution	640 x 480 pixels
Power Supply	100-240 VAC, 50/60 Hz
ECG	3/5/12-lead
IBP	Up to 4 channels
Battery Backup	Yes
Certifications	CE, UL, CSA
Parameters Monitored	ECG, SpO2, NIBP, IBP, Temperature, Respiration, Cardiac Output
Connectivity	Ethernet, USB, Serial
Display Type	TFT LCD
Recorder	Integrated thermal printer
Battery Type	Lithium-ion
Operating Temperature	0 to 40°C
Storage Temperature	-20 to 60°C
Humidity Range	15% to 95% non-condensing
Display Size	10.4 inches
Cardiac Output	Available
