GE Dash 4000 Service Manual

Field replaceable units: Replace main unit parts
2000966-542D Dash 3000/4000/5000 7-39
8. If you installed the Nellcor OxiMax or Masimo SET SPO2 and 4 BP
SuperStat upgrade, place the labels as shown below.
9. Complete the procedures in “Recommended checkout” on page 7-52.
Masimo SET or
Nellcor OxiMax
827B
DINAMAP SUPERSTAT
BP 1/3 and BP 2/4
12SL (if software
option was enabled)
CO2, NBP, and ECG
NOTE
The BP 1/3 and BP 2/4 label looks similar to the example below.
860A
patent
disclosure label
004B

GE Dash 4000 Specifications

General

Resolution	640 x 480 pixels
Power Supply	100-240 VAC, 50/60 Hz
ECG	3/5/12-lead
IBP	Up to 4 channels
Battery Backup	Yes
Certifications	CE, UL, CSA
Parameters Monitored	ECG, SpO2, NIBP, IBP, Temperature, Respiration, Cardiac Output
Connectivity	Ethernet, USB, Serial
Display Type	TFT LCD
Recorder	Integrated thermal printer
Battery Type	Lithium-ion
Operating Temperature	0 to 40°C
Storage Temperature	-20 to 60°C
Humidity Range	15% to 95% non-condensing
Display Size	10.4 inches
Cardiac Output	Available
