GE ImageQuant LAS 4000 User Manual

Result: The following dialog is displayed.
1
Enter a Name for the method.
2
Select appropriate settings for Light, Filter and Iris.
3
Click OK.
Note:
Optical characteristics can be corrected using the Flat Frame Calibration function for the
added Method. See Section 5.12.2 Flat Frame Calibration, on page 105.
5.13 Help menu
User Manual
Opens the ImageQuant LAS 4000 User Manual in the default pdf browser.
Getting Started
Opens the Getting Started with ImageQuant LAS 4000 manual in the default pdf browser.
End-User License Agreement
Opens the End-User License Agreement in the default pdf browser.
Sensitivity/Resolution
The figure showing the relation between sensitivity and resolution is displayed. Click to close the window.
ImageQuant LAS 4000 User Manual 28-9607-42 AB 107
5 Software reference guide
5.12 Option menu
5.12.3 Method Setting

GE ImageQuant LAS 4000 Specifications

General

Brand	GE
Model	ImageQuant LAS 4000
Category	Laboratory Equipment
Language	English
