GE ImageQuant LAS 4000 - Changing the UV Transilluminator or White Light Table

Peak wavelengthNameType
365 nmUV Epi light
Incident
460 nmBlue Epi light
520 nmGreen Epi light
630 nmRed Epi light
460nm orRGB module (3-color Epi light)
520nm or
630 nm
710 nmNIR Epi light
-White Epi light
3.3.1 Changing the UV transilluminator or white light table
The UV transilluminator and white light table are exchanged as follows:
1
If neither the UV transilluminator or white light table are currently in place inside the instrument,
proceed to step 4.
2
Turn the lever holding the light source to unlock it.
3
Pull out the light source carefully along the guide while holding it with both hands.
28 ImageQuant LAS 4000 User Manual 28-9607-42 AB
3 Exchanging accessory parts
3.3 Changing the light sources
3.3.1 Changing the UV transilluminator or white light table
