GE ImageQuant LAS 4000 - Exposing Repeatedly (Repetition)

ActionStep
Adjust the gradations of the exposed image(s) as described above, then save and print the image(s).
8 Click the Complete button.
The display returns to the initial screen.
Note:
Only the last 100 images can be kept. Previous images are discarded.
4.11 Exposing repeatedly (Repetition)
The Repetition exposure type enables a series of images to be exposed consecutively. Each image is
recorded separately and data is not accumulated. This section describes how to perform this type of
experiment.
Place a sample on the tray that you selected according to the type of a sample. Put the tray in the
ImageQuant LAS 4000 then close the door.
Note:
•
Make sure that the tray is placed at the required position.
6
5
4
3
1
2 7
64 ImageQuant LAS 4000 User Manual 28-9607-42 AB
4 Operating the ImageQuant LAS 4000
4.10 Exposing consecutively (Increment)
