3-8 L90 LINE CURRENT DIFFERENTIAL SYSTEM – INSTRUCTION MANUAL
PANEL CUTOUTS CHAPTER 3: INSTALLATION
3
For side-mounting L90 devices with the standard front panel, use the following figures.
Figure 3-7: Vertical side-mounting installation (standard front panel)
