GE LOGIQ e Basic Service Manual

Set Up Docking Cart
LOGIQ e – Basic Service Manual 11-31
5461614-100 English Rev. 6
Install 3-Probe Port to Docking Cart (continued)
5. Rotate the lock 90° counterclockwise and release your
hand, the lock automatically springs in the lock position.
Refer to picture 5.
Figure 11-12.
6. Mount the probe connector to the Docking Cart. Refer to
picture 6.
Figure 11-13.
