LPS-O Line Protection System GE Power Management
3.1 CASE ASSEMBLY 3 HARDWARE DESCRIPTION
3
Figure 3–4: CIRCUIT BOARD LOCATIONS
BUS CARD
960 CPU BOARD
OPTION SWITCH
DSP / ANI BOARD
DIGITAL INPUTS /
SCADA BOARD
MAGNETICS
MODULE
DIGITAL OUTPUTS / POWER SUPPLY
BOARD
MAGNETICS SERIAL
EPROM CONNECTOR
FRONT PANEL
CONNECTORS
