GE Power Management LPS-O Line Protection System 10-
9
10 ALPS-TEST PROGRAM 10.3 FILE MENU
10
302
Z3PHREACH
Z3 Phase Reach
303
Z3PCHARANG
Z3 Phase Characteristic Angle
402
Z4PHREACH
Z4 Phase Reach
403
Z4PCHARANG
Z4 Phase Characteristic Angle
1401
POSSEQANG
Pos. Seq. Impedance Angle
1402
ZERSEQANG
Zero Seq. Impedance Angle
1404
ZEROSEQK0
Z0 / Z1 ratio
1601
MOBZONE
Coordinating Zone
1602
MOBCHARANG
MOB Characteristic Angle
This menu item results in a dialog box supplied by Microsoft. Therefore only the
OK
button of the dialog box is
tested to make sure the file was properly opened.
Select
Open Setting File
from the
File
menu. Select a file that is not a setting file and not a test file.
Verify the following:
• A message box is displayed that explains the error.
• The currently active test has not changed from before the open command.
Select
Open Setting File
from the
File
menu. Select a setting file containing no errors and click the
OK
button
to open it. Select each test.
Verify that the values in each dialog box which correspond to settings are the same as those in the setting file.
Edit an existing setting file using a text editor. Remove a setting line which contains a user entered value.
Select
Open Setting File
from the
File
menu. Select the edited setting file. Select a test that uses the setting
value that was deleted.
Verify the following:
• No error message is displayed.
• The corresponding test value is the default value.
10.3.4 CLOSE TEST FILE
Save the currently active test file. Select
Close Test File
from the
File
menu. Window is cleared from the
screen thus closing the test.
Modify the currently active test file. Select
Close Test File
from the
File
menu. A message box will be dis-
played asking if you want to save the file. Click the
OK
button. The file is saved under the current name. The
window is cleared from the screen thus closing the test.
• Verify that the file contains the modified values by looking at the file with a text editor.
Modify the currently active test file. Select
Close Test File
from the
File
menu. A message box will be dis-
played asking if you want to save the file. Click the
Cancel
button. The file is not closed.
Verify the window is not cleared from the screen and that the test file contains the modified inputs.
Modify the currently active test file. Select
Close Test File
from the
File
menu. A message box will be dis-
played asking if you want to save the file. Click the
No
button. The file is not saved. The window is cleared from
the screen thus closing the test.
• Verify that the file does not contain the modified values by looking at the file with a text editor.
