13 XPRESSION BUILDER 13.3 XPRESSION BUILDER FLAGS
13
Table 13–7: DISTANCE UNITS
INDEX DESCRIPTION MNEMONIC
65 Zone 1 AB Distance Function Z1AB
66 Zone 1 BC Distance Function Z1BC
67 Zone 1 CA Distance Function Z1CA
68 Zone 2 AB Distance Function Z2AB
69 Zone 2 BC Distance Function Z2BC
70 Zone 2 CA Distance Function Z2CA
71 Zone 3 AB Distance Function Z3AB
72 Zone 3 BC Distance Function Z3BC
73 Zone 3 CA Distance Function Z3CA
74 Zone 4 AB Distance Function Z4AB
75 Zone 4 BC Distance Function Z4BC
76 Zone 4 CA Distance Function Z4CA
77 Any Zone 1 Phase Distance Function Z1PH
78 Any Zone 2 Phase Distance Function Z2PH
79 Any Zone 3 Phase Distance Function Z3PH
80 Any Zone 4 Phase Distance Function Z4PH
132 Zone 2 Phase Timer Z2PTMR
133 Zone 3 Phase Timer Z3PTMR
134 Zone 4 Phase Timer Z4PTMR
106 TL1 Timer Output TL1
126 Ground Forward Flag (NT) GRDFWD
127 Ground Reverse Flag (NB) GRDREV
Table 13–8: MISCELLANEOUS
Index Description Mnemonic
138 Number of Breaker Operation Alarm BRMNOP
139 Breaker Equipment Duty Alarm BRMNDT
60 Fault ID: Phase A Involved DAFLTA
61 Fault ID: Phase B Involved DAFLTB
62 Fault ID: Phase C Involved DAFLTC
63 Fault ID: Neutral Involved DAFLTN
64 DMA Overrun DMAOVR
147 Trip Circuit #1 Voltage Monitor Status T1TC
148 Trip Circuit #2 Voltage Monitor Status T2TC
149 Trip Circuit #3 Voltage Monitor Status T3TC
150 Trip Circuit #4 Voltage Monitor Status T4TC
