GE Power Management LPS-O Line Protection System 2-
33
2 CALCULATION OF SETTINGS 2.5 REFERENCE TABLES
2
T
ABLE
2–6: INDEX NUMBERS – &21),*85$%/( /2*,&  352*5$00$%/( 287387 6,*1$/6
TABLE 2–6: INDEX NUMBERS (Sheet 1 of 8)
Index Description
Mnemonic
33 Trip Bus TRIP
34 Not used
35 Not used
36 Not used
37 Initial Reclose from Scheme
Logic
RI
38 Reclose Cancel Output from
Scheme Logic
CANCL
39 Spare
40 Spare
41 Spare
42 Spare
43 Warm Restart WARMST
44 Spare
45 Line Over Load Alarm Output LNOVLD
46 Critical Alarm Output CRTALM
47 Spare
48 Trip Circuit Alarm TCMALM
49 Zone Flags On Alarm ZNALM
50 Overcurrent Alarm OVRALM
51 Unbalanced Current Detector
Alarm Output
UNBAL
52 Non-Critical Alarm Output NCALM
53 Spare
54 Spare
55 Spare
56 MANUAL OPEN BRK1 MNOPN1
57 MANUAL OPEN BRK2 MNOPN2
58 MANUAL CLOSE BRK1 MNCLS1
59 MANUAL CLOSE BRK2 MNCLS2
60 Fault ID: Phase A Involved DAFLTA
61 Fault ID: Phase B Involved DAFLTB
62 Fault ID: Phase C Involved DAFLTC
63 Fault ID: Neutral Involved DAFLTN
64 DMA Overrun DMAOVR
65 Zone 1 AB Distance Function Z1AB
66 Zone 1 BC Distance Function Z1BC
67 Zone 1 CA Distance Function Z1CA
68 Zone 2 AB Distance Function Z2AB
69 Zone 2 BC Distance Function Z2BC
70 Zone 2 CA Distance Function Z2CA
71 Zone 3 AB Distance Function Z3AB
72 Zone 3 BC Distance Function Z3BC
73 Zone 3 CA Distance Function Z3CA
74 Zone 4 AB Distance Function Z4AB
75 Zone 4 BC Distance Function Z4BC
76 Zone 4 CA Distance Function Z4CA
77 Any Z1 Phase Distance Function Z1PH
78 Any Z2 Phase Distance Function Z2PH
79 Any Z3 Phase Distance Function Z3PH
80 Any Z4 Phase Distance Function Z4PH
81 Spare
82 Spare
83 Spare
84 Spare
85 Spare
86 Spare
87 Spare
88 Spare
89 Spare
90 Spare
91 Spare
92 Spare
TABLE 2–6: INDEX NUMBERS (Sheet 2 of 8)
Index Description
Mnemonic
