GE LPS-O - Page 75

GE Power Management LPS-O Line Protection System 2-
35
2 CALCULATION OF SETTINGS 2.5 REFERENCE TABLES
2
151 Spare
152 Spare
153 PHASE A OVERVOLTAGE AVOVR
154 PHASE B OVERVOLTAGE BVOVR
155 PHASE C OVERVOLTAGE CVOVR
156 Spare
157 Spare
158 Spare
159 Spare
160 Any Phase Overvoltage OVRVLT
161 Programmable Logic Gate #1
Output
G1
162 Programmable Logic Gate #2
Output
G2
163 Programmable Logic Gate #3
Output
G3
164 Programmable Logic Gate #4
Output
G4
165 Programmable Logic Gate #5
Output
G5
166 Programmable Logic Gate #6
Output
G6
167 Programmable Logic Gate #7
Output
G7
168 Programmable Logic Gate #8
Output
G8
169 Programmable Logic Gate #9
Output
G9
170 Programmable Logic Gate #10
Output
G10
171 Programmable Logic Gate #11
Output
G11
172 Programmable Logic Gate #12
Output
G12
173 Programmable Logic Gate #13
Output
G13
174 Programmable Logic Gate #14
Output
G14
TABLE 2–6: INDEX NUMBERS (Sheet 5 of 8)
Index Description
Mnemonic
175 Programmable Logic Gate #15
Output
G15
176 Programmable Logic Gate #16
Output
G16
177 Programmable Logic Gate #17
Output
G17
178 Programmable Logic Gate #18
Output
G18
179 Programmable Logic Gate #19
Output
G19
180 Programmable Logic Gate #20
Output
G20
181 Programmable Logic Gate #21
Output
G21
182 Programmable Logic Gate #22
Output
G22
183 Programmable Logic Gate #23
Output
G23
184 Programmable Logic Gate #24
Output
G24
185 Programmable Logic Gate #25
Output
G25
186 Programmable Logic Gate #26
Output
G26
187 Programmable Logic Gate #27
Output
G27
188 Programmable Logic Gate #28
Output
G28
189 Programmable Logic Gate #29
Output
G29
190 Programmable Logic Gate #30
Output
G30
191 Programmable Logic Gate #31
Output
G31
192 Programmable Logic Gate #32
Output
G32
193 Programmable Logic Gate #33
Output
G33
194 Programmable Logic Gate #34
Output
G34
TABLE 2–6: INDEX NUMBERS (Sheet 6 of 8)
Index Description
Mnemonic
