Figure 3. SD Transceivers offer compatibility with older MDS x710
Transceivers (right), and may be used for replacement and/or
interoperability in these networks. A retrofit kit is available for
connector conversion (see Table 1).
2.5 Accessories and Spares
Table 1 lists common accessories and spare items for the transceiver.
GE MDS also offers an Accessories Selection Guide listing additional
items that may be used with the product. Visit www.gemds.com or contact
your factory representative to obtain a copy of the guide.
Table 1. Accessories & Spare Items
Accessory Description Part Number
DC Power Plug,
2-pin, polarized
Mates with power connector on radio
case. Screw terminals provided for
wires, threaded locking screws to
prevent accidental disconnect.
73-1194A53
Retrofit Kit, Digital Contains adapters and connectors
needed to facilitate the replacement
of an existing MDS x710A/C/M
digital transceiver.
03-4696A01
Retrofit Kit, Analog Contains adapters and connectors
needed to facilitate the replacement
of an existing MDS x710A/C/M
analog transceiver.
03-4697A01
Setup Guide
(for Packet and
Transparent Modes)
Describes the installation and setup
of the transceiver. A companion to
this Technical Manual.
05-4847A01
Flat Mounting
Brackets
(Standard)
Brackets that attach to the bottom of
the unit. Used for mounting to a flat
mounting surface.
03-4123A14
Flat Mounting
Brackets
(x710-compatible)
Brackets that attach to the bottom of
the unit. Used for mounting to a flat
mounting surface. Bracket matches
MDS x710 Transceiver mounting
holes.
Consult
Factory
