D
IRECTION 5771498-100, REVISION 5 VENUE™ SERVICE MANUAL
Chapter 5 - Venue™Components and Function (Theory) 5-25
PRELIMINARY
5-9-4 Back End Interface (BIB) Board
The purpose of the Back End Board (BIB) module is to unify communications from all the boards in the
system and redirect them to their relevant destinations.
The Back End Board (BIB) module, responsible for the scanner Interfaces, comprises three main
Interfaces:
• Back End (mITX standard)- via the Docking Interface
• Csound Front End (CFE) Board
• Main Power Board (MPB)
5-9-5 Solid State Hard Drive
The Hard Disk is the main storage device of the Venue™ ultrasound unit. The Hard Disk, which is
controlled by the CPU via signals from the SATA Bus.
