D
IRECTION 5771498-100, REVISION 6 VENUE™ SERVICE MANUAL
Chapter 10 - Care and Maintenance 10-5
PRELIMINARY
Section 10-4
Tools Required
10-4-1 Tools Required for Servicing the Venue™
The following tools (TORX bits or drivers) are needed to service the ultrasound scanner.
Screw diameter and standard torque values are also included. If the torque is not indicated with the
procedure, hand-tighten the screws/nuts.
Table 10-3 Tools Used for Servicing the Venue™
Item No. Tool Size Torque Comments
1.
Bit # TX-10
M2.5
• Use Torque specified in procedure.
• If the torque is not indicated with the procedure, hand-tighten the screws/nuts.
• 90 degree “L“ are suggested.
• A full set of 90 degree “L“TORX wrenches are recommended.
2.
Bit # TX-15
M3
3.
Bit # TX-20
M4
4.
Bit # TX-25
M5
5.
Bit # TX-30
M6
6.
Bit # TX-45
M10
7.
Socket Set
(must include 7mm socket)
8.
Side cutter (diagonal)
5 or 6 inch
9.
Flat Blade Driver
3.2 mm
10.
Flat Blade Driver
4 mm
11.
Flat Blade Driver
6 mm
12.
Phillips Driver
PH1
13.
Phillips Driver
PH2
14.
Phillips Driver
PH3
15.
Hex Key
1.5 mm
(Unbrako Key / Allen Key)
16.
Hex Key
2 mm
(Unbrako Key / Allen Key)
17.
Hex Key
2.5 mm
(Unbrako Key / Allen Key)
18.
Hex Key
3 mm
(Unbrako Key / Allen Key)
19.
Hex Key
4 mm
(Unbrako Key / Allen Key)
20.
Hex Key
5 mm
(Unbrako Key / Allen Key)
21.
Hex Key
6 mm
(Unbrako Key / Allen Key)
22.
Hex Key
8 mm
(Unbrako Key / Allen Key)
23.
Hex Key
10 mm
(Unbrako Key / Allen Key)
24.
Hex Key
M12
Rear Casters: 130 Nm (Unbrako Key / Allen Key)
25.
Nut Driver
5 mm
26.
Nut Driver
3/16 inch
27.
Torque Wrench
Up to 130 Nm
Heavy mechanical parts may need a specific torque.
Each procedure will indicate the torque needed.
