IRECTION 5771498-100, REVISION 5 VENUE™ SERVICE MANUAL
5-30 Section 5-12 - Peripherals
PRELIMINARY
Section 5-12
Peripherals
5-12-1 Internal Peripheral
5-12-1-1 Black & White Digital Graphic Printer
The B/W Printer, available as an option. The printer is mounted at the front side of the Venue™
ultrasound scanner.
5-12-1-2 ECG Module
The ECG module, available as an option. The module is responsible for the acquisition of the ECG
analog signal inputs.
5-12-2 External Peripherals
5-12-2-1 Wi-Fi Adapter
The Wi-Fi adapter allows the user to connect the system to network wireless.
The Wi-Fi adapter is connected at the back side of the cockpit (monitor) via a L shape USB adapter.
5-12-2-2 Bar-code reader
The bar code reader allows the user scanning patient ID from a printed bar code label and scanning
needle type bar code.
The bar code reader is connected to the Venue system via a USB port located on the rear.
USE ONLY APPROVED, DEFIBRILLATION-PROOF ECG PATIENT CABLES, SEE Table 9-20.
