GE Venue R2

Chapter 8 - Replacement Procedures 8-111
D
IRECTION 5771498-100, REVISION 6 VENUE™ SERVICE MANUAL
PRELIMINARY
8-7-2 MPB TO Cockpit Cable Replacement Procedure
8-7-2-1 Tools
• Appropriate Phillips screwdriver
• Flat-head screwdriver
8-7-2-2 Time Required
15 min
8-7-2-3 Preparations
1.) Shut down the Venue™ ultrasound unit, as described in Power Shut Down .
2.) Make sure the On/Off power switch is set to Off.
3.) Make sure the system is standing securely on a level surface, with the wheels in the locked position.
8-7-2-4 MPB TO Cockpit Cable Removal Procedure
1.) Remove all accessories.
2.) Remove the following covers: Lower Front eTower, Left side eTower, Right Side eTower, and Riser
Thermal covers,,
3) Perform MPB removal procedure.
4.) For systems with rear cockpit cable cover installed, perform the following steps:
a.) Disconnect the Wi-Fi adapter.
• Accessories - Replacement Procedures
• RS Probe Cover Removal Procedure
• Lower Front eTower Cover Removal Procedure
• Left Side eTower Cover Removal Procedure
• Right Side eTower Cover Removal Procedure
• MPB Door Cover Removal Procedure
• Riser Thermal Cover Removal Procedure
• MPB Module Removal Procedure
• Wi-Fi Adapter Removal Procedure
