8-40 Section 8-4 - System Modules- Replacement Procedures
D
IRECTION 5771498-100, REVISION 6 VENUE™ SERVICE MANUAL
PRELIMINARY
8-4-6 PSU Module Replacement Procedure
8-4-6-1 Tools
Appropriate Phillips screwdriver.
8-4-6-2 Time Required
15 min
8-4-6-3 Preparations
1.) Shut down the Venue™ ultrasound unit, as described in Power Shut Down .
2.) Make sure the On/Off power switch is set to Off.
3.) Make sure the system is standing securely on a level surface, with the wheels in the locked position.
8-4-6-4 PSU Module Removal Procedure
1.) Remove all accessories.
2.) Remove the following covers: RS Probe Cover, Lower Front eTower cover, Right Side eTower
Cover and the Left Side eTower Cover:.
3.) Remove the MPB door.
4.) Remove the two battery packs
Refer to Table 9-10 on page 9-10.
• Accessories - Replacement Procedures
• RS Probe Cover Removal Procedure
• Lower Front eTower Cover Removal Procedure
• Right Side eTower Cover Removal Procedure
• Left Side eTower Cover Removal Procedure
• MPB Door Cover Removal Procedure
• Battery Module Removal Procedure
